Magnafuel Mp-9940-B Efi Fuel Pressure Regulator – Adjustable Billet Aluminum Unit

Description

Brand: MagnaFuel
Manufacturer’s Part Number: MP-9940-B
Part Type: Fuel Pressure Regulators
Product Line: MagnaFuel EFI Fuel Pressure Control Units
Automotive Fittings Part Number: MRF-MP9940-B
UPC: 819315002162
Regulator Pressure (psi): 35-85
Regulator Style: Return
Regulator Location: Inline
Boost/Vacuum Reference Port: Yes
Boost/Vacuum Rise Ratio: 1:1
Gauge Port: Yes
Inlet Quantity: 4
Regulator Inlet Size: -8 AN
Inlet Attachment: Female straight cut O-ring
Return Fitting Size: -8 AN
Return Attachment: Female straight cut O-ring
Fittings Included: No
Regulator Material: Aluminum
Regulator Color: Purple
Rebuildable: Yes
Mounting Bracket Included: Yes
Remanufactured: No
Quantity: Sold individually.
Notes: Boost reference fitting included
Description:
MagnaFuel EFI fuel pressure control units feature a unique guided-metering valve assembly to provide a more accurate metering of fuel flow and help reduce the pressure drop that can occur at high or sudden changes in fuel demand. The pressure control units are designed to work with the EFI 600 pump and are available in two sizes–large for applications of up to 2,000+ hp and standard for applications of up to 700 hp. Each of these units has a 1/8 in. NPT pressure port for a gauge, a filtered vent fitting or optional boost reference fitting, and is compatible with racing gasoline and alcohol. The units feature a CNC-machined, aircraft-quality aluminum body and are hand-assembled and flow-tested for maximum performance.
